HLE-1 Encoder


Product Description

The HTTP Live streaming rack encoder

The HLE-1 is an encoder for HTTP Live streaming (HLS 1.1). The HLE-1 will encode a multi rate stream ranging from a few kbit up till several Mbit. The encoder has SDI or HDMI input and enables the adaptive distribution of WMT or any other source to different devices including Android, Apple and Windows.

The Mobile Viewpoint HLE-1 encoder accepts both HD SDI video, as well as RTSP IP streams coming from Mobile Viewpoint WMT encoders. It transcodes them to HLS web streams, which can be distributed by Content Delivery Networks, already in use by customers. On top of this, the Mobile Viewpoint HLE-1 encoder integrates fully with the drag ‘n drop WMT LinkMatrix, giving users full flexibility in choosing which encoder gets sent to the HLE-1 encoder and HD SDI Playout devices.


Specifications

VOLTAGE/USAGE

  • Input : 110V - 220V
  • Usage : +- 65 Watt

VIDEO INPUT

  • SDI / HDMI
  • IP stream

PHYSICAL CARACTERISTICS

  • Housing: SECC sheet Aluminum
  • Weight: 3,5 kg
  • Mounting: 19” inch

ENVIRONMENTAL LIMITS

  • Operational Temperature -25 to 55 °C (-13 to 131 °F)
  • Ambiant Relative Humidity 5 to 95% (non-condensing)

VIDEO INPUT FORMATS

  • HD 1080i50, 720p60, 540p
  • NTCS/PAL

RELIABILITY

  • Alert Tools : Built-in buzzer and RTC
  • Automatic Reboot Trigger
  • Built-in WDT (watchdog timer)

VIDEO ENCODING

  • Adaptive HLS
  • H.264 high profile 4.1

ETHERNET INTERFACE

  • LAN: auto-sensing 10/100 Mbps ports
  • Magnetic Isolation Protection: 1.5 KV



  • key Features

    • HTTP Live Streaming encoder
    • Multi rate stream
    • SDI or HDMI input
    • Fully integrated within MVP LinkMatrix
    • Transport to edge servers via Webdav
